SAE1020 1022 Automotive Steel Tubes For Shock Absorber Damper

Name: SAE1020 1022 Automotive Steel Tubes For Shock Absorber Damper
Brand: TORICH
Price: 1 USD

Best SAE1020 1022 Automotive Steel Tubes For Shock Absorber Damper wholesale

Brand Name : TORICH

Model Number : SAE 1020

Certification : ISO9001; ISO14001; TSI16949

Place of Origin : ZheJiang,CHINA

MOQ : 3 tons

Price : negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 60000 Ton per year

Delivery Time : 30-35 days

Packaging Details : packing in wooden boxes or in hexagonal bundles

Product name : SAE1020 1022 Shock Absorber Damper Steel Tube For Automobile

Product Keyword : Shock Absorber Steel Tube

Grade : 1020

Application : Auto industry/ machinery use/ Oil Cylinder Tube

Secondary : Non-secondary

Section shape : Round

Contact Now

SAE1020 1022 Shock Absorber Damper Steel Tube For Automobile

Size range:

O.D.: 5-420mm W.T.: 0.5-50mm Length: max12000mm

Application:

For Auto industry/ machinery use/ Oil Cylinder Tube/ Motorcycle shock absorber

Steel Grade and Chemical Composition:

	AISI SAE 1020 Steel Chemical Composition (%)
UNS	Steel Grade	C	Mn	P (≤)	S (≤)
G10200	1020	0.18-0.23	0.30-0.60	0.040	0.050

Physical Properties and Mechanical Proporties:

Melting point: 1515 °C (2760 °F)

Density of 1020 steel: 7.87 g/cm3

Material 1020 thermal conductivity
Value (W/m·K)	Temperature, °C (°F)
51.9	0 (32)
51.0	100 (212)
48.9	200 (392)

Specific Heat of AISI 1020 Carbon Steel
Value (J/Kg·K)	Temperature, °C (°F)
486	50-100 (122-212)
519	150-200 (302-392)
599	350-400 (662-752)

Electrical Resistivity of AISI SAE 1020 Carbon Steel
Value (μΩ·m)	Temperature, °C (°F)
0.159	0 (32)
0.219	100 (212)
0.292	200 (392)

AISI SAE 1020 coefficients of linear thermal expansion
Value (10^-6/K)	Temperature, °C (°F)	Treatment or condition
11.7	20-100 (68-212)	Annealed
12.1	20-200 (68-392)
12.8	20-300 (68-572)
13.4	20-400 (68-752)
13.9	20-500 (68-932)
14.4	20-600 (68-1112)
14.8	20-700 (68-1292)

AISI 1020 steel mechanical properties in heat-treated or cold-worked conditions
Steel (UNS)	Tensile strength, MPa (ksi)	Yield strength, MPa (ksi)	Elongation in 50 mm, %	Reduction in area, %	Hardness (HB)	Processing, condition or treatment	Sample Size, mm (in.)
1020 (G10200)	380 (55)	205 (30)	25	50	111	Hot rolled	19-31.8 mm (0.75-1.25 in.)
1020 (G10200)	420 (61)	350 (51)	15	41	121	Cold drawn	19-31.8 mm (0.75-1.25 in.)

		ASTM AISI SAE 1020 steel mechanical properties in the hot-rolled, normalized, and annealed condition
UNS	Grade	Tensile strength, MPa (ksi)	Yield strength, MPa (ksi)	Elongation in 50 mm, %	Reduction in area, %	Hardness (HB)	Processing, condition or treatment	Austenitizing temperature, °C (°F)	Quenching agent	Izod impact strength, J, (ft·lbf)	Sample Size
G10200	1020	448 (65)	331 (48)	36	59	143	As-rolled	–	Oil	87 (64)	12.8 mm (0.505 in.) machined from 25.4 mm (1 in.) rounds.
		441 (64)	346.5 (50.3)	35.8	68	131	Normalized	870 (1600)	Oil	118 (87)
		394.7 (57.3)	295 (43)	36.5	66	111	Annealed	870 (1600)	Oil	123 (91)

		Cyclic fatigue properties
UNS	Grade	Cyclic strength coefficient, MPa (ksi)	Fatigue strength coefficient, MPa (ksi)	Fatigue strength exponent	Fatigue ductility coefficient	Fatigue ductility exponent	Hardness (HB)
G10200	SAE 1020 steel	1205 (175)	850 (123)	-0.12	0.44	-0.51	108

SAE1020 1022 Automotive Steel Tubes For Shock Absorber Damper

Q: Are you trading company or manufacturer ?

A: A professional steel pipes materials inventor, manufacturer and solution provider

Q: How long is your delivery time?

A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample of ss inox 304 316 Inside and outerside hexagonal pipe for free charge but need pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
